Citizen CT-S2000 - Fn = 64: Function 64 Sending Key Code List of Defined NV Graphics

- 91 -
fn = 64: Function 64 Sending Key Code List of Defined NV Graphics
GS ( L pL pH m fn d1 d2 
[Code] <1D>H<28>H<4C>H<pL><pH><m><fn><d1><d2>
[Range] (pL + pH x 256) = 4 (pL = 4, pH = 0)
m = 48
fn = 64
d1 = 75 (“K”)
d2 = 67 (“C”)
[Outline] Sends the key code list of defined NV graphics.
• When key code list is present
Hex. Decimal Data Size
Header 37H 55 1 byte
Identifier 72H 114 1 byte
Status
40Hor41H 64or65
1 byte
Data 30H~39H 48~57 2~ 80 bytes
NUL 00H 0 1 byte
• When key code is not present
Hex. Decimal Data Size
Header 37H 55 1 byte
Identifier 72H 114 1 byte
Data 40H 64 1 byte
NUL 00H 0 1 byte
When 40 or more key codes are present, they are sent by being divided in unit of
40max.
• Status with continuous transmission data group is 41H.
• Status without continuous transmission data group is 40H.
After sending [Header - NUL], receives a response from the host and executes the
next processing corresponding to the response.
• In case of “Status (with continuous block): hexadecimal number = 41H / decimal
number = 65”
Response
ASCII Decimal
Content of Processing
ACK 6  Sends next data group.
NAK 21 Resends previous data group.
CAN 24 Cancels processing.
• In case of “Status (last block): hexadecimal number = 40H / decimal number = 64”
Response
ASCII Decimal
Content of Processing
ACK 6 Terminates processing.
NAK 21 Resends previous data group.
CAN 24 Cancels processing.
