Citizen CT-S2000 Command Reference

- 139 -
DLE DC4 fn d1...d7 (Specification of fn = 8)  
[Function] Buffer clear
[Code] <10>H<14>H<fn><d1> ...<d7>
[Range] fn = 8, d1 = 1, d2 = 3, d3 = 20, d4 = 1, d5 = 6, d6 = 2, d7 = 8
[Outline] • Erases all data in receiving buffer or print buffer.
• Sends the following 3-byte data group.
Hex. Decimal No. of Data
Header 37H 55 1 byte
Identifier 25H 37 1 byte
NULL 00H 0 1 byte
• Enters the state of selecting STANDARD MODE.
[Caution] • When receiving a code row coinciding with the code configuring this command, the
same operation as this command takes place and attention by the user is required.
Example: When corresponding code row is present in bit image data.
• This command must not be used between other command code rows.
Example: This command is used in bit image data.
• This command is ignored during transmission of block data.
[See Also] ESC p

Citizen CT-S2000 Specifications

General

Maximum resolution	203 x 203 DPI
Autocutter	Yes
Autocutter durability	2 million cuts
Maximum roll diameter	102 mm
Supported paper width	58, 60, 80, 82.5 mm
Standard interfaces	Ethernet
Connectivity technology	Wired
Dimensions (WxDxH)	147 x 207 x 147 mm
Certification	UL, C-UL, FCC A, TUV-GS, C
Internal memory	0.375 MB
Built-in barcodes	Code 39, Code 93
Mean cycles between failures (MCBF)	200000000
Compatible operating systems	Windows 2000 / XP / VISTA / 2003 Server, OPOS1.8, CUPS
Product color	Black
Power requirements	100 - 240 V, 50/60 Hz, 150 VA
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
