- 168 -
Before an FF is sent (170th line), the following program code can be added to remove part of the data.
180 PRINT #1, CHR$(&H1B);"W";CHR$(72);CHR$(0);CHR$(120);CHR$(0);
190 PRINT #1, CHR$(36);CHR$(0);CHR$(48)CHR$(0);
200 PRINT #1, CHR$(&H18);
As a result of the additional program code, a print-out is executed as shown in Figure 4-5 “Print Result of
Adding a Program of Example 3 to Example 2”, where the string “GHI” is removed.
When strings are removed with CAN, the area where the string would have been is not used by the rest of
the data, instead it is converted into a sequence of spaces.
(0,0) 200
Page Mode lesson 2 Paper
CAN command
ABCDEF JKLMNOP
QRSTU1234567890
400 Print area
Print Direction
Figure 4-5 Print Result of Adding a Program of Example 3 to Example 2
