- 63 -

• Drawer kick-out connector status (n = 2, 50)

Bit Status Hex. Decimal

Status of pin 3 of drawer kick connector = “L” 00 0

Status of pin 3 of drawer kick connector = “H” 01 1

1 Undefined — —

2 Undefined — —

3 Undefined — —

4 Unused 00 0

5 Undefined — —

6 Undefined — —

7 Unused 00 0

[See Also] Appendix 4.3 “Identification of Send Status”
