TIC QUANTUM Electric System
10/04 12-25
Dip
switch
Position Factory pre-
set position
Meaning for
QUANTUM
Meaning for SPRINT
5 On (top) Operation of knife frame only by
means of key button housing
970 917.1, including complete
opening or closing
Operation of knife frame by means of
key button housing 970 917.1,
including complete opening or
closing
5 Off
(bottom)
Off (bottom) Knife frame may be operated by
means of key button housing
970 917.1 to remove plugging,
complete opening and closing of
knife frame by pushbutton
972 234.0.
Pushbutton 972 234.0 not provided
6 On (top) 2-speed motor may be started
manually (9+S)
not possible
6 Off
(bottom)
Off (bottom) 2-speed motor may be started
manually (9+S)
Basic position
7 Off (bottom) Spare (not used yet) Spare (not used yet)
8 On (top) Off (bottom) Spare (not used yet) Spare (not used yet)
2.5.2 Table
Dip
switch
Position Factory pre-
set position
1999 series
Setting for QUANTUM,
corresponds to factory pre-set
position for 1999 series
Setting for SPRINT
1 Off (bottom)
2 On (top) On (top)
2 Off (bottom) Off (bottom) Off (bottom)
3 On (top)
3 Off (bottom) Off (bottom) Off (bottom) Off (bottom)
4 On (top) On (top)
4 Off (bottom) Off (bottom) Off (bottom)
5 On (top) On (top)
5 Off (bottom) Off (bottom) Off (bottom)
6 On (top) Off (bottom)
6 Off (bottom) Off (bottom) Off (bottom)
7 On (top)
7 Off (bottom) Off (bottom) Off (bottom) Off (bottom)
8 On (top)
8 Off (bottom) Off (bottom) Off (bottom) Off (bottom)
