TIC QUANTUM Operation
10/04 3-19
3.1 Control box short instructions
Loading operation
Pick-up down
Pick-up up. The pick-up does not switch off.
Floor conveyor ON/OFF when loading, tailgate must be closed.
Knife frame
Open knife frame
Close knife frame
When pressing both keys simultaneously, the knife frame is opened
completely.
Unloading operation
Open tailgate
Close tailgate
Floor conveyor ON/OFF when unloading, tailgate must be open.
Articulated drawbar
Articulated drawbar up
Articulated drawbar down
