Claas QUANTUM 3500 - Control Box Short Instructions; Operation

TIC QUANTUM Operation
10/04 3-3
1.1 Control box short instructions
Control system ON
Control system OFF
Loading operation
Pick-up up/down
Dry crop top up/down
(Quantum 3500 K only)
Wagon full indicator
Knife frame
Opens / closes the cutting trough
Opens the cutting trough totally
Unloading operation
Opens / closes the tailgate
Articulated drawbar
Drawbar up/down
