Operation QUANTUM TIC
3-6 10/04
Unloading operation
Use this key of the control box to switch on the control unit. The
indicator light lights up.
Silo operation
For silo operation raise the wagon at the front with the articulated
drawbar. Use this key for pre-selecting the articulated drawbar and
set the single-acting control valve to the pressure setting. When
unloading is complete, lower the wagon again. Set the control unit
to the float position.
Discharging the load
QUANTUM 3500 S
Attention If the swash plates are folded down, opening the tailgate is not allowed.
Open the tailgate before unloading. Use this key for pre-selecting
the tailgate and set the single-acting control valve to the pressure
setting.
Open the tailgate to enable activation of the shredder drums via the pto.
Then initiate the floor conveyor using the double-acting control valve. The
floor conveyor speed can be varied using the rotary knob. To close the
tailgate, the set the single-acting control valve to the float position until
the tailgate has closed completely.
Discharging the load
QUANTUM
2500 K / P
3500 K / P
3800 K / P
Open the tailgate before unloading. Use this key for pre-selecting
the tailgate and set the single-acting control valve to the pressure
setting.
Initiate the floor conveyor using the double-acting control valve. To
close the tailgate, the set the single-acting control valve to the float
position until the lock has engaged.
To reverse the floor conveyor, move the lever of the double-acting
control valve to the opposite direction. If the tractor is fitted with a flow
rate controller, this can be used to vary the floor conveyor speed.
