Group 19, Motor Controls
SM 765, Sep ’06 Description • 19-1-3
Standard Fault Codes
The control has over 75 fault codes assist the service tech-
nicians and operators in the trouble shooting the vehicle.
If mis-operation of the vehicle occurs, a fault code will be
displayed on the Dash Display of the vehicle, or by plug-
ging the handset into the "B: plug of the master controller
and reading the fault code.
With the fault code number, follow the procedures out-
lined in Group 19, Section 03 ,"Fault Codes", section to
determine the problem and a solution.
Stored Fault Codes
This feature records the last 5 fault codes in controller.
The last 5 fault codes can be accessed through the alarm
log using a handset, or a laptop computer with the PcCon-
sole software and adapter cable. The faults are stored with
the hour meter reading when the fault first happened, the
number of time the fault has happened, and the tempera-
ture the first time the fault happened.
Hour Meter Readings
When the traveling speed is less than 0.5km/h, it displays
the accumulated operating hour.
Battery Discharge Indication (BDI)
Provides accurate battery state of charge information to
the vehicle operator, Features and Functions:
Displays 100 to 0 percent charge in 10% incre-
ments.
Lift Circuit is disabled at 10% discharge
Handset
This is a multifunctional tool used with the AC controls.
The handset (Clark part #8033636) has a display and a
key board for data entry.
Features and functions:
Monitor existing fault codes for both traction and
pump controls.
Monitor hour meter readings on traction and pump
controls.
Monitor or adjust the control functions
Use as a tester to monitor input and output infor-
mation.
N
O
TE
The Handset instructions and Troubleshoot-
ing can be found in Group 19, Section 3 of
this manual.
Protection Features
Reverse Battery Polarity:
The MAIN CONTACTOR is there to protect the control-
ler against reverse battery polarity and for safety reasons.
Connection Errors:
All inputs are protected against connection errors.
Thermal Protection:
If the controller temperature exceeds 80° C, the maximum
current is reduced in proportion to the thermal increase.
The temperature can never exceed 100° C.
External Agents:
The controller is protected against dust and the spray of
liquid to the degree of protection meeting IP54.
Protection Against Uncontrolled Movement:
The main contactor will not close if:
The power unit is not functioning
The controller is not functioning perfectly.
The output of the accelerator does not fall
below the minimum voltage value stored, with
1V added
Running microswitch is in closed position.
Low Battery Charge:
When the battery charge is low, -66 Code, the maximum
current is reduced to half the maximum current pro-
grammed.
Protection against accidental startup:
A precise sequence of operations is necessary before the
control will start (SRO). Startup cannot occur if the
