Group 19, Motor Controls
19-2-12 • Control Programming SM 765, Sep ’06
TESTER MENU
The most important input or output signals can be measured in real time using the TESTER function of the handset. The
handset acts as a multimeter able to read voltage, current and temperature. The following is a list of measurements for
different configurations.
Handset Tester: user can verify the state of the following parameters:
SLAVE CONTROL
Slave Control - "Dualac2 Power 80V"
Motor voltage (%) Current RMS (A) Back switch (ON/OFF)
Frequency (Hz) Temperature (°C) Enable switch (ON/OFF)
Encoder (Hz) Seat switch (ON/OFF) Voltage booster (%)
Slip Value (Hz) Forw switch (ON/OFF) Battery voltage (V)
1) MOTOR VOLTAGE: This is the voltage supplied to the motor by the controller; it is expressed as a percentage
of full battery voltage.
2) FREQUENCY: This is the frequency of the voltage and current supplied to the motor.
3) ENCODER: This is the speed of the motor, expressed in the same unit of the frequency; this informa-
tion comes from the speed sensor.
4) SLIP VALUE: This is the difference of speed between the rotating field and the shaft of the motor,
expressed in the same unit of the frequency.
5) CURRENT RMS: Root Mean Square value of the motor current.
6) TEMPERATURE: The temperature measured on the aluminum heat sink holding the MOSFET devices.
7) SEAT SWITCH: The level of seat microswitch digital input.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
8) FORWARD SWITCH: The level of the Forward direction digital input FW.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
9) BACKWARD SWITCH: The level of the Reverse direction digital input BW.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
10) ENABLE SWITCH: The level of the Enable digital input.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
11) VOLTAGE BOOSTER: This is the booster voltage supplied to the motor in load condition; It is expressed in a per-
centage of the full voltage.
12) BATTERY VOLTAGE: Level of the battery voltage measured at the input of the key switch.
