Clark GEX20 - Page 141

Group 19, Motor Controls
SM 765, Sep ’06 Control Programming • 19-2-11
Slave Control - "Dualac2 Power (80V)"
Submenu "Adjustments"
1. SET BATTERY TYPE: Selects nominal battery voltage
2. ADJUST BATTERY: Fine adjustment of the battery voltage measured by the controller.
See Group 19, Section 4 for GEX Factory Control Settings
GEX Handset
Slave Control Configuration
Main Menu Set Model Connected to 4 (Slave) (3 = Master, 5 = Pump)
Parameter
Set Options Not Available
Change
Adjustments Set Battery Type 48/72/80/96
Adjust Battery
Tester Motor Voltage %
Aux Output Voltage
Frequency Hz
Encoder Hz
Slip Value Hz
Current RMS A
Temperature
Seat Switch On/Off
Forward Switch V
Reverse Switch V
Enable Switch On/Off
Voltage Booster %
Battery Voltage V
Save
Parameter
Restore
Parameter
Alarms
Program
VACC
VACC Settings Min/Max
Motor Data Not Available
HEADING
Not Available
DISPLAY
KEYBOARD
