Group 19, Motor Controls
19-2-10 • Control Programming SM 765, Sep ’06
15) ENABLE SWITCH: The level of the Enable digital input.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
16) SEAT SWITCH: The level of seat microswitch digital input.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
17) CUTBACK SWITCH: The level of the Speed Reduction microswitch.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
18) CUTBACK SWITCH2: The level of the Speed Reduction microswitch.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
19) BRAKE SWITCH: The level of the brake microswitch.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
20) EXCLUSIVE HYDRO: Status of the exclusive hydro switch.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open.
21) BRAKE PEDAL POTI: Voltage of the brake potentiometer's wiper (CPOTB). The parameter is active only if
the "PEDAL BRAKING" parameter is set to "ANALOG".
22) HAND BRAKE: The level of the Handbrake microswitch.
ON /+BV = input active, switch closed.
OFF / GND = input non-active, switch open
23) VOLTAGE BOOSTER: This is the booster voltage supplied to the motor in load condition; It is expressed in a
percentage of the full voltage.
24) BATTERY VOLTAGE: Level of the battery voltage measured at the input of the key switch.
25) BATTERY CHARGE: The percentage charge level of the battery.
