Group 32, Tilt Cylinders
SM 765, Nov ’06 Tilt Cylinder Specifications and Description • 32-1-1
Specifications
See Group 30 for hydraulic system specifications.
Tilt Cylinder Type: Double-acting
Maximum Operating Pressure: 21,000 kPa (3,000 psi)
Tilt Ranges*:
Abbreviations: Std = Standard, high-visibility upright;
TSU = Triple-stage upright; MFH = maximum fork
height; B = back tilt; F = forward tilt. See truck data plate
for upright MFH.
Fastener Torques
Rod-End Yoke Bolts: 166-193 N.m (122-142 ft-lb)
Rod-End Pin Lock Plate Fasteners: 40-45 N⋅m (30-33 ft-
lb).
Base Mount Pin Lock Plate Fasteners: 40-45 N⋅m (30-33
ft-lb).
Service Intervals
Tilt Cylinder Drift Test: Every 50-250 hours or each PM.
Tilt Cylinder Check and Adjustment: Every 50-250 hours
or each PM.
Tilt Cylinder Rod Seal Condition Check: Every 50-250
hours or each PM.
Tilt Cylinder Mounting Check and Tightening: Every 50-
250 hours or each PM.
Tilt Cylinder Rod-End Check and Tightening: Every 50-
250 hours or each PM.
Tilt Cylinder Rod-End Lubrication: Every 50-250 hours
or each PM.
Description
The tilt cylinders provide backward and forward tilt of the
upright. The forward and back tilt angles are governed by
the cylinder stroke and by use of spacers and different
length rod ends. The tilt cylinders are pin-mounted to the
truck frame and upright using yokes, clevises, and pins.
Pins are held in place by a lock plate and fastener to pre-
vent the pins from working their way out.
The tilt cylinders are serviced by removing them from the
truck and disassembling them for complete overhaul,
including installation of new seals and or other cylinder
components.
The tilt lock valve is integrated into the tilt section of the
main hydraulic control valve. The tilt lock valve prevents
the upright from tilting forward when the truck is not run-
ning. The tilt lock valve is not serviceable and must be
replaced as a valve section if defective.
MAST
TYPE
MFH mm(in)
BACK
"B"( ˚ )
FORWARD
"F"( ˚ )
GEX
STD ~2015(83) 8 8
STD 2680(105.5)~3860(152) 8 8
STD 4165(164)~4620(182) 5 6
STD 5170(203.5) 5 3
TSU 3860(152)~4800(189) 5 6
TSU 5050(199)~6100(240) 5 3
TSU 6370(251)~ 3 3
QUAD ALL 3 3
Section 1
Tilt Cylinder Specifications and Description
