Group 40, Specifications
40-2-4 • General Specifications SM 765, Sep ’06
Steering Column and Gear Specifications
Steering System Type: Hydrostatic power steeing.
Steering System Relief Pressure Setting: 10,000 kPa
(1450 psi)
Steer Axle Specifications
Steer Cylinder Type: Double-acting, piston-type.
Hydraulic Sump, Filters, and Pump
Specifications
Hydraulic Pump Type: Integral gear type pump and motor
assembly.
Sump Type and Capacity: Removable tank mounted in
truck side frame with maximum capacity of 25 L (6.6 gal-
lons)
Hydraulic Fluid Type: Clark Hydraulic Fluid specification
MS-68.
Hydraulic Fluid Filters: Return line filter and suction line
screen mounted in sump.
Return Filter Type: Disposable, 25 micron, full flow.
Suction Screen: 100 mesh stainless steel screen.
Hydraulic Valve/Lift Circuit Specifications
Rated Flow: 75 L/min (20 gpm)
Counterweight and Chassis Specifications
Counterweight weights:
Tilt Cylinders Specifications
Tilt cylinder type: double-acting with shims
Maximum Operating pressure: 21,000 kPa (3,045 psi; 210
bar)
Tilt Ranges
(Abbrcviations - Std = Standard, high-visibility upright;
TSU = Triple-stage upright HI-LO:Full Free lift upright;
MFH = maximum fork height: B = back tilt; F = forward
Lilt)
Upright Specifications
Upright Weight: approximately 341 kg (753 lb) to approx-
imately 971 kg (2140 lb)
Carriage Weight: approximately 136 kg (300 lb)~150kg
(330 lb)
Fork Weight: approximately 50-62 kg each (110-137 lb)
IMP
RTANT
Before hoisting, the weights of upright, car-
riage, and forks must be combined to deter-
mine what lifting capacity is required of the
hoisting equipment.
Capacities and Lift Heights: Upright, carriage, and fork
capacity and upright lift heights are listed on the truck’s
data plate.
Lubricants:
All Purpose Grease (Clark specifications MS-9)
Innerslide Lubricant (Clark part #886396)
Chain and Cable Lube (Clark part #886399)
Short wheel base
28.2 BC
Long wheel base
33.9 BC
560 kg (1235 lbs) GEX20 -
760 kg (1675 lbs) GEX25 -
720 kg (1587 lbs) - GEX30
MAST
TYPE
MFH mm(in)
BACK
"B"( ˚ )
FORWARD
"F"( ˚ )
GEX
STD 2015(83)~3860(152) 8 8
STD 4165(164)~4620(182) 5 6
STD 5170(203.5)~ 5 3
TSU 3860(152)~4800(189) 5 6
TSU 5210(199)~6100(240) 5 3
TSU 6370(251)~ 3 3
QUAD ALL 3 3
