89 750-265
Each alert log record has the format described in Table 38.
CB Falcon alert codes are contained in Table 39.
Table 38. CB Falcon Alert Log Record.
Byte Offset Parameter Read/Write Format Note
0-1 Alert code R U16 See Table 39.
2-5 Cycle R U32 See registers 128-129 (decimal).
6-9 Hours R U32 See registers 130-131 (decimal).
10 -- R U8 Unused
11 Occurrence count R U8 Number of occurrences of most recent alert.
Table 39. CB Falcon Alert Codes.
Code Description Note
0 None No alert
1 Alert PCB was restored from factory defaults
2 Safety configuration parameters were restored from factory defaults
3 Configuration parameters were restored from factory defaults
4 Invalid Factory Invisibility PCB was detected
5 Invalid Factory Range PCB was detected
6 Invalid range PCB record has been dropped
7 EEPROM lockout history was initialized
8 Switched application annunciation data blocks
9 Switched application configuration data blocks
10 Configuration was restored from factory defaults
11 Backup configuration settings was restored from active configuration
12 Annunciation configuration was restored from factory defaults
13 Annunciation configuration was restored from backup
14-17 RESERVED
18 Alarm silence time exceeded maximum
19-26 RESERVED
27 Safety processor was reset
28 Application processor was reset
29 Burner switch was turned OFF
30 Burner switch was turned ON
31 PIM was inserted into socket
32 PIM was removed from socket
33 Alert PCB was configured
34 Parameter PCB was configured
35 Range PCB was configured
