CleaverBrooks CFC User Manual

833-3577 CB-FALCON SYSTEM OPERATOR INTERFACE
65-0296—01 44 750-241
CH enable Disable or Enable Central
Heating Loop
617
CH demand
source
Sensor for Central Heat
demand:
Sensor only
Sensor & STAT terminal
Sensor & Remote Stat
LCI & Sensor
CH sensor Which sensor to use for Central
Heat modulation
Outlet sensor
Header sensor
CH setpoint Setpoint for normal Central
Heat modulation:
-40 °C - 130 °C (-40 °F - 266
°F)
CH time of
day setpoint
Setpoint when Time Of Day
switch is on. -40 °C - 130 °C (-
40 °F - 266 °F)
CH off
hysteresis
Differential above setpoint
when boiler is turned off. -40 °C
- 130 °C (-40 °F - 266 °F)
CH on
hysteresis
Differential from setpoint when
boiler is turned on.-40 °C - 130
°C (-40 °F - 266 °F)
CH
hysteresis
step time
Time between hysteresis step
changes: 0-600 seconds
(0=Disable hysteresis stepping)
CH outdoor
reset
Enabled
Disabled
CH P-gain Time between hysteresis step
changes: 0-100
CH I-gain Time between hysteresis step
changes: 0-100
CH D-gain Time between hysteresis step
changes: 0-100
Table 42. Configurable Parameters. (Continued)
Parameter Comment
Table
#
Page
#
CH maximum
outdoor
temperature
-40 °C - 130 °C (-40 °F - 266
°F)
717
CH minimum
outdoor
temperature
-40 °C - 130 °C (-40 °F - 266
°F)
CH minimum
water
temperature
-40 °C - 130 °C (-40 °F - 266
°F)
CH outdoor
boost time
0-600 seconds
CH outdoor
boost
maximum
setpoint
-40 °C - 130 °C (-40 °F - 266
°F)
Lead Lag
maximum
outdoor
temperature
-40 °C - 130 °C (-40 °F - 266
°F)
Lead Lag
minimum
outdoor
temperature
-40 °C - 130 °C (-40 °F - 266
°F)
Lead Lag
minimum
water
temperature
-40 °C - 130 °C (-40 °F - 266
°F)
Lead Lag
outdoor
boost time
0-600 seconds
Lead Lag
outdoor
boost
maximum
setpoint
-40 °C - 130 °C (-40 °F - 266
°F)
Table 42. Configurable Parameters. (Continued)
Parameter Comment
Table
#
Page
#
