8-4 Chapter 8: Service 98-148248-C
7. Click Download next to the text Statistics report.
8. Save the statistics report to your computer.
8.1.1.3 Event list
Events are registered. When an event is registered, the web interface shows an event icon
in the icon bar as long as the event is active. Active events are also displayed in the
ACU display. To view the event list with active events, click the event icon from the icon bar
at the top of the web interface, or select HELPDESK > Event list from the left navigation
pane.
The Event list page shows a detailed list of active events and notifications including the
time of the first occurrence, ID and severity of the event message, and a short text
describing the error. Active events are cleared from the event list when the error is cleared.
They are moved to the section Notifications and are displayed for 24 hours. All entries in
the section Notifications are cleared automatically after 24 hours and after restart of the
system. For a list of all events with description, error code (ID), explanation and remedy see
List of ADU events on page D-2 and List of ACU events on page D-7. You can clear the
event history in the diagnostic report, this will not change the configuration.
To clear the event history do as follows:
1. Click Factory default in the ADMINISTRATION page.
2. Click the button Clear event history.
8.1.1.4 Self test
You can start a self test of the SAILOR 600 VSAT Ka ADU and ACU. The self test checks all
vital parts of the antenna and ACU. You can restart the antenna or the terminal (ADU and
ACU). If a malfunction is detected, the unit provides system messages with a description of
the failing test. This is indicated in the icon bar in the web interface and in the ACU display.
You find all system messages in System messages on page D-1. An extended antenna
POST is available, this test lasts longer and checks more components than the regular self
test.
Figure 8-2: Web interface: Clear event history
