List of ADU events
D-2 Appendix D: System messages 98-148248-C
D.2 List of ADU events
List of 07-09-20
Error code Unit Severity Description Explanation
0A001-0 Antenna ERROR Production data Production data is invalid.
0A002-0 Antenna ERROR XIM internal Antenna configuration data stored in the PCM
module is invalid.
0A003-0 Antenna ERROR XIM external Antenna configuration data stored in the VIM module
is invalid.
0A004-0 Antenna ERROR XIM I/X match Antenna configuration data stored in the PCM
module does not match the configuration data stored
in the VIM module.
0A005-0 Antenna ERROR Antenna type The configured antenna type is not supported or
unknown.
0A006-0 Antenna ERROR PCM FPGA load The PCM FPGA cannot be initialised and loaded
correctly.
0A007-0 Antenna ERROR XIM FPGA load The VIM FPGA cannot be initialised and loaded
correctly.
0A008-0 Antenna ERROR XIM production Production/calibration data stored in the VIM module
is invalid.
0A00A-0 Antenna ERROR GNSS initialisation The GNSS device cannot be initialised. Check cable
and GNSS device.
0A014-0 Antenna ERROR AMB device discovery Missing one or more of the following devices: ISM,
DDM/DMD/FDM and PMM. Check cables.
0A015-0 Antenna ERROR Azi DDM ABS device Cannot initialise the azimuth DDM/DMD/FDM. Info:
0x00000000: Device not found (possible cabling
problem)
0x0000bbaa: Device internal error (replace device)
aa=status, bb=state.
0A016-0 Antenna ERROR Xel DDM ABS device Cannot initialise the cross-elevation DDM/DMD/FDM.
Info: See 0A015-0.
0A017-0 Antenna ERROR Ele DDM ABS device Cannot initialise the elevation DDM/DMD/FDM. Info:
See 0A015-0.
0A018-0 Antenna ERROR ISM ABS device Cannot initialise the ISM Info:
0x00000000: Device not found (possible cabling
problem)
0 x 0 0 0 c b b a a : D e v i c e i n t e r n a l e r r o r ( r e p l a c e d e v i c e )
aa=status, bb=state, c=calibration data error.
0A019-0 Antenna ERROR PMM ABS device Cannot initialise the PMM. Info: See 0A015-0.
0A01A-0 Antenna ERROR BCM ABS device Cannot initialise the BCM. Info: See 0A015-0.
Table D-1: ADU event messages
