SAILOR 600 VSAT Ka system components
A-4 Appendix A: Technical specifications 98-148248-C
A.1.3 ACU
Item Specification
Dimensions, rack mount
H x W x D
1U, 19 inch
4.4 x 48 x 33 cm (1.75 x 19 x 13 inch)
Weight 4.5 kg (10 lbs)
Connections ACU -
modem
Delivered with cable for iDirect X7 modem
Ambient temperature Operational: -25°C to +55°C
Storage: -40°C to +85°C
Humidity EN 60945 protected, 95% (non-condensing)
IP class IP30
Compass safe distance AC input (7016C): 0.3 m (12 inch) to EN 60945
Interfaces 1 x N-Connector for antenna RF Cable (50 Ohm) with automatic cable loss
compensation
1 x NMEA 0183 for Gyro/GPS compass input (prepared for NMEA 2000)
2 x F-Connectors (75 Ohm) for modem Rx and Tx
1 x Ethernet (User)
1 x Ethernet (Management)
1 x Ethernet (Modem)
1 x Ethernet (ThraneLink, service, setup etc.)
1 x RS-232 data (modem control)
1 x RS-422 data (modem control)
1 x AC power input
1 x Grounding bolt
Input power See System power supply range and Total system power consumption in
Table A-1 on page A-1.
Modem interface (control) Generic, iDirect openAMIP protocol & custom protocol
Display and controls Web interface, OLED (red) display, 5 push buttons, 3 discrete indicator
LEDs and ON/OFF switch
No transmit zones Programmable, 8 zones with azimuth and elevation
Table A-3: Technical specifications for the ACU
