Calibration
6-10 Chapter 6: Configuration 98-148248-C
5. Select Enable in the section Azimuth calibration (active satellite profile). To be able
to use this feature there must be a valid satellite profile and you must activate it in
SETTINGS > Satellite profiles.
6. Click Apply.
7. Switch on the modem.
Azimuth calibration with a service profile
1. Click SERVICE > Calibration.
2. Select the service profile in the drop down list Satellite. All profiles with the modem
Service & calibration are displayed in the list. If there is no profile in the list, you must
set up one, see Service profile for calibration on page 6-10.
3. Click Start in the section Azimuth calibration and wait typically 5 minutes for the
calibration to finish. After finished calibration a message with the result of the
calibration is displayed in the field Result.
6.3.2 Service profile for calibration
Use the service profile for calibration if you do not want to use the automatic azimuth
calibration or if you want to enter the satellite parameters directly on the calibration page.
To prepare for calibration you can set up a service profile for calibration. To set up a service
profile do as follows:
1. Connect a PC to LAN connector 3 (Service port, standard Ethernet) of the ACU or to the
front LAN connector of the ACU.
2. Open an Internet browser and enter the IP address of the ACU (Default:
http://192.168.0.1).
3. Select ADMINISTRATION and log on with User name: admin, Password: 1234
4. Select SETTINGS > Satellite profiles > New entry. Enter the name of the satellite
profile for calibration (a name of your own choice).
5. Select the modem profile Service & Calibration from the drop-down list.
