Keypad and menus of the ACU
98-148248-C Chapter 6: Configuration 6-45
6666
Example: EVENT 1/4*: This is the first event out of a list of 4 and there has been a
change in the list. EVENT 1/4 will always be shown, the * indicates that there
has been a change.
6.6.4 Brightness of the display
To adjust the brightness do the following:
1. Press and hold OK for a short moment until BRIGHTNESS XXX% is displayed (XXX is the
current brightness value).
2. Hold OK pressed + press for lighter or for darker display.
3. Release OK to leave the brightness menu.
6.6.5 Power-cycle of the ACU and ADU
To power cycle the ACU and ADU do the following:
1. Press and hold and until the ACU display shuts down and the ACU and ADU
reboots.
2. Wait until the system has rebooted and is operational again. The last active satellite
profile will be used.
LNB LO LOW Current LNB Local Oscillator frequency, low band (GHz), selected
in the satellite profile
EVENT menu Description
<EVENT> In this menu all active events are listed. Use
and to go through
the active events.
Events can be of the type WARNING or ERROR.
If a new event occurs or there is a change in the event list while you are in
the EVENTS menu, a * is shown in the upper left corner of the display,
next to the menu name. Press OK to update the EVENTS list, the * will be
removed.
A > means the event text is longer than the display. Press > to see the
remaining text.
Table 6-19: EVENTS menu of the ACU
SATELLITE menu Description
Table 6-18: SATELLITE menu of the ACU (Continued)
Figure 6-34: Reset the system
Main NAV:GH MDM: NETOK LAN: 1 – 3 4
TRACKING
6$7:5;/+7;0$5
