Keypad and menus of the ACU
6-44 Chapter 6: Configuration 98-148248-C
NET LED LED indication from modem. Steady or flashing
green/amber/red, OFF
STAT LED
TX LED
RX1 LED
RX2 LED
PWR LED
TEMP LED
FAN LED
NETWORK menu Description
PORT 1 IP Current IP address for LAN 1
MASK 1 Current netmask for LAN 1
PORT 3 IP (LAN 3) Current IP address of the SAILOR 600 VSAT Ka
web interface (default: http://192.168.0.1)
MASK 3 (LAN 3) Current netmask of the SAILOR 600 VSAT Ka
web interface (default: 255.255.255.0)
PORT 4 IP Current IP address for LAN 4
MASK 4 Current netmask for LAN 4
DEFAULT GATEWAY Current default gateway
Table 6-17: NETWORK menu of the ACU
SATELLITE menu Description
POSITION Position of the current satellite
RX POLARISATION LHC or RHC
TX POLARIZATION X-POL or CO-POL
RX FREQUENCY Ka band receiving frequency of the active satellite, auto-selected
by modem
LNB LO 18.25 GHz, system hardware.
BUC LO 28.05 GHz, system hardware
TX FREQUENCY Current TX frequency
LNB LO HIGH Current LNB Local Oscillator frequency, high band (GHz), selected
in the satellite profile
Table 6-18: SATELLITE menu of the ACU
MODEM menu Description
Table 6-16: MODEM menu of the ACU (Continued)
