Keypad and menus of the ACU
98-148248-C Chapter 6: Configuration 6-43
6666
Menu descriptions
SATELLITE Current satellite information. This information is selected using the
web interface.
EVENTS System events. Active events are shown as: X ACTIVE EVENTS in the
MAIN display. Press OK to update the list.
Top-level menu Description
Table 6-14: Top-level menus of the ACU (Continued)
ANTENNA menu Description
POINTING ANTENNA STATE: Current state of the antenna, e.g. TRACKING
ELEVATION: Current elevation angle of the antenna
AZIMUTH: Current azimuth of the antenna, with reference to North
POLARISATION RX POLARISATION: LHC or RHC.
TX POLARISATION: X-POL or Co-POL.
GPS LATITUDE: current latitude, read from GPS module.
LONGITUDE: current longitude, read from GPS module.
FIX TYPE: 2D or 3D or NONE
HEADING Ship’s heading in degrees with reference to North, provided by the
ship’s gyro
VERSIONS Current software version
SERIAL
NUMBERS
ACU: ACU serial number
ADU: Serial number of the antenna
LOCAL ADMIN Shows that the ACU is set into local administration mode. Only user
name admin is needed and the ACU is in admin mode for 1 hour.
Table 6-15: ANTENNA menu of the ACU
MODEM menu Description
MODEM TYPE Connected modem type
TX ENABLE On or off, information delivered by the connected modem
RX LOCK On or off, information delivered by the connected modem
Table 6-16: MODEM menu of the ACU
