Appendix A
AAAA
Technical specifications A
This appendix has the following sections:
• SAILOR 600 VSAT Ka system components
• Outline drawings
• X7 Modem BUC & Console to ACU cable
A.1 SAILOR 600 VSAT Ka system components
A.1.1 General specifications
Item Specification
Frequency band
Rx
Tx
Ka-Band (e.g. THOR 7)
19.2 to 20.2 GHz
29.0 to 30.0 GHz
Reflector size 65 cm (25.5 inch)
Certification Compliant with CE (Maritime), ETSI, RoHS, REACH
System power supply range 100-240 VAC
Total system power consumption 240 W peak, 135 W typical DC (VSAT modem not included)
ADU cable type (ACU to ADU) Single 50 Ohm coax cable for Rx, Tx, ACU-ADU modem and power
ACU to ADU cable, requirements RF loss at 1950 MHz < 20 dB, 4450 MHz < 35 dB.
DC Resistance: < 0.9 Ohm.
Antenna connector at the ADU Female N-Connector (50 Ohm)
Antenna connector at the ACU Female N-Connector (50 Ohm)
Table A-1: General specifications
