Supported commands
98-148248-C Appendix E: Command line interface E-9
EEEE
E.2.10 track
Command Description
track
Shows the sub commands available, including a short
description.
track mode
track mode dvb
Shows or sets the receiver bandwidth or mode, the way
the SAILOR 600 VSAT Ka tracks the satellite:
• narrow (recommended, uses the built-in 300 kHz
filter of the SAILOR 600 VSAT Ka)
• rssi (uses the RSSI signal from the VSAT modem)
• wide (uses the wide-band filter to track the satellite)
• dvb (uses the built-in DVB-S2 receiver of the SAILOR
600 VSAT Ka to track the satellite. You must
configure dvb_sym and dvb_nid.)
• GSC (uses Inmarsat Global Signalling Channel
• GSCpwr (uses power of Inmarsat Global Signalling
Channel)
track dvb_sym
track dvb_sym 22
Shows or sets the current mega symbols rate for the
DVB-S2 receiver when in dvb mode. The symbol rate
used to verify and track a transponder.
• Valid range: 0.1 — 99
track dvb_nid
track dvb_nid 0
Shows or sets the DVB NID to be verified by the built-in
DVB-S2 tracking receiver, when using tracking mode
DVB. It configures the NID used to verify and track a
transponder.
• Valid range: 0 — 65535
A NID of ‘0’ disables the NID check. Then the NID
will be omitted in the verification of the
transponder.
track rx_rf_freq
The frequency for the receiver to tune to. Verify that
the frequency is in the same range as the modem
rx_rf_frequency, above or below 11.7 GHz. I.f
rx_rf_freq is set to 0, the tracking frequency is the same
as the RX frequency provided by the modem
•Valid range:
Ku band: 10.7 GHz to 12.75 GHz
Ka band: 19.2 GHz to 20.2 GHz
Table E-11: UCLI command: track
