Flow chart for dual antenna mode
B-10 Appendix B: Antenna Diversity Solution (ADS) 98-148248-C
B.4 Flow chart for dual antenna mode
OTC procedure: During start up the Modem sends a command to select antenna 1
(master) and checks whether the OTC calibration data is up to date. If not, OTC is started on
antenna 1. When done, the Modem restarts and checks if antenna 1 is up to date, and OTC
is started on antenna 2 (slave). When done, the Modem restarts. The process for the entire
OTC for 2 antennas may take up to 16 minutes. If a BUC is exchanged in one of the
antennas, the OTC is only done for the modified antenna and the total time for OTC is
shorter.
Figure B-9: Flow chart
Installing SAILOR VSAT for Dual antenna operation (ADS)
Hardware Installation Configure Master Configure Slave OTC
Mechanical
mounting
RF cables to
ADU’s
splitters and
Modem
Ethernet cables
ACU to modem
ACU master to switch
ACU slave to switch
Power and
Ground cables
Master & Slave *)
ACU
Power on
START
Configure modem
profile
Configure satellite
profile
Configure heading
input
Configure blocking
and switching
zones
Perform azimuth
calibration
Perform TX cable
calibration
Enable
Dual Operation
Configure modem
profile
”Dual Antenna
Master”
Configure satellite
profile
”Dual Antenna
Master”
Configure heading
input
Configure blocking
and switchi ng
zones
Perform azimuth
calibrati on
Perform TX cable
calibrati on
Modem
Power on
Line up
Pointing,
acquisition &
tracking
Establish
Network
link
*) do NOT power on Modem
