98-148248-C 6-1
Chapter 6
6666
Configuration 6
This chapter has the following sections:
• Introduction to the built-in web interface
• Heading input and position system
• Calibration
• Configuration with the web interface
• Keypad and menus of the ACU
• SNMP support
6.1 Introduction to the built-in web interface
6.1.1 Overview
With the built-in web interface of the SAILOR 600 VSAT Ka ACU you make a full
configuration of the SAILOR 600 VSAT Ka. You can use a standard Internet browser.
Installation of software is not necessary.
For quick start instructions see Heading input and position system on page 6-4.
6.1.2 Connecting to the web interface
To connect to the web interface of the ACU do as follows:
1. Switch on the ACU.
2. Wait until the LEDs on the front plate of the ACU show that the system is ready to be
configured.
•Power LED: Green
• Logon LED: Off
• Fail/Pass LED: Flashing green during power-on self test, after that steady green.
3. Connect a PC to LAN port 3: Service (standard Ethernet) of the ACU or to the front LAN
connector of the ACU.
The SAILOR 600 VSAT Ka system is not designed to be connected directly to
the Internet. It must be located behind a dedicated network security device
such as a fire wall.
