List of ADU events
98-148248-C Appendix D: System messages D-3
DDDD
System messages
0A01E-0 Antenna ERROR Sensor sanity Too many invalid values measured by the ISM during
initialisation. Check for vibrations or malfunctioning
ISM.
0A021-0 Antenna ERROR Azi axis calibration Azimuth axis zero reference not found. Check belt and
zero reference module. Info:
0x00000001: Timeout (operation did not complete in
time)
0x00000010: Encoder or mechanical problem
0x00000020: Zero reference not found
0x00000040: End stop not found.
0A022-0 Antenna ERROR Xel axis calibration Cross-elevation axis zero reference or end stops not
found at expected locations. Check belt, zero
reference module, and end stops. Info: See 0A021-0.
0A023-0 Antenna ERROR Ele axis calibration Elevation axis zero reference or end stops not found
at expected locations. Check belt, zero reference
module, and end stops. Info: See 0A021-0.
0A025-0 Antenna ERROR Antenna calibration One or more errors occurred during antenna start-up
Info:
0x00000001: Timeout (calibration did not complete
in time)
0x00000010: Azimuth axis
0x00000020: Cross-elevation axis
0x00000040: Elevation axis
0x00000080: Polarisation axis
0A028-0 Antenna ERROR Demodulator load The second receiver demodulator cannot be
initialised and loaded correctly.
0A029-0 Antenna ERROR XIM PLL lock The PLL on the VIM does not lock.
0A02B-0 Antenna ERROR ABS software version The ABS software version in the antenna is too old to
match the hardware requirements. Upload new
software via the web interface.
0A02D-0 Antenna ERROR BUC reference switch The BUC reference switches do not work. Check PCM-
VIM cable and replace cable, VIM or PCM.
0A034-0 Antenna WARNING ACU communication The communication link between ACU and antenna is
not working.
0A035-0 Antenna WARNING ISM data valid Sensor measurements from the ISM are invalid. This
indicates a malfunctioning ISM.
0A036-0 Antenna WARNING ISM data range Sensor measurements from the ISM are out of range.
0A037-0 Antenna WARNING GNSS communication Lost connection to the GNSS device.
0A038-0 Antenna WARNING GNSS data range Received information from the GNSS device which is
out of range.
0A039-0 Antenna WARNING GNSS device warning Local GNSS device warning.
0A03A-0 Antenna WARNING GNSS device error Local GNSS device error.
Error code Unit Severity Description Explanation
Table D-1: ADU event messages (Continued)
