List of ADU events
D-6 Appendix D: System messages 98-148248-C
0A05B-0 Antenna WARNING Ele cal. limits Check limits of the calibration result for the elevation
axis are exceeded. Pointing performance may be
degraded. Info: See 0A059-0.
0A05D-0 Antenna WARNING ISM warning The ISM has temporarily observed an unusual
situation for temperature or voltage. No user
interaction required. If repeated after cooldown and
reboot, check if the ISM or cables around it are
defective.
0A05E-0 Antenna WARNING Low elevation The antenna is not allowed to transmit because the
elevation is too low.
0A05F-0 Antenna WARNING Heading range Heading data range error. External heading unit
supplies unreliable data.
0A062-0 Antenna WARNING High elevation The antenna cannot perform acquisition in gyro-free
mode because the elevation is too high.
0A063-0 Antenna WARNING BCM warning The BCM has observed an unusual situation with
regards to the PLL. If the situation persists, check the
BCM.
0A064-0 Antenna ERROR BCM communication Communication error between PCM and BCM. Check
SUB-D connectors and cables.
0A065-0 Antenna ERROR Deploy/Stow Deploy/stow error. The antenna did not properly
unlock (deploy), or the stow switch never closed
(stow).
0A066-0 Antenna ERROR OMT error Problem with OMT. Temperature out of range or OMT
cable may be broken.
0A067-0 Antenna WARNING Automatic stow The antenna automatically stowed because it
detected significant movement.
0A068-0 Antenna WARNING Polarisation tuning Polarisation tuning was not successful. Polarisation
may be incorrect.
0A069-0 Antenna ERROR BCM error The BCM PLL failed to initialize.
0A06A-0 Antenna WARNING Missing BUC response No response received from the BUC.
0A06C-0 Antenna FATAL Antenna base tilt Antenna base tilted beyond limit.
0A06D-0 Antenna WARNING VMU reference
distribution
VMU reference signal not present at BCM, but is
present at ACU. Check coax cable between VIM and
BCM.
0A06E-0 Antenna WARNING Antenna orientation The terminal is oriented in a way that prevents it from
pointing to the selected satellite.
Error code Unit Severity Description Explanation
Table D-1: ADU event messages (Continued)
