Configuration with the web interface
6-20 Chapter 6: Configuration 98-148248-C
TX allowed Yes or no. Indicates if the modem supplies the 50 MHz reference signal
on its TX connector (On) and if an iDirect OpenAMIP modem indicates
modem Locked and Tx ON in the OpenAMIP message L (L 1 1).
Yes = Terminal is allowed to transmit
No = Terminal is not allowed to send data over the satellite interface.
a. Items shown in this list may vary, they depend on the current modem.
POINTING Description
Azimuth, elevation geo Current value for azimuth, elevation, relative to the vessel
heading.
Azimuth, elevation rel. Current value for azimuth, elevation, relative to the vessel.
Table 6-8: Web interface, DASHBOARD, POINTING section
TX Description
BUC TX On or Off. Shows if the SAILOR 600 VSAT Ka has enabled the BUC
or not. It is the same TX ON/TX OFF as shown in the display of the
ACU, see ACU display and keypad on page 6-40.
Table 6-9: Web interface, DASHBOARD, TX section
MODEM
a
Description
Table 6-7: Web interface, DASHBOARD, MODEM section (Continued)
