38
Rotate Handle
Adjusts the rotation of the region (clockwise or counter-clockwise). When using the Nudge buttons or a keyboard to rotate the graphic, the
graphic is rotated one degree in the specified direction. When the Rotate handle is active, the current rotation (in degrees) is displayed.
Bend Handle
Adjusts the bend of the region (used to create arc-shaped and annular regions). When using the Nudge buttons or a keyboard to adjust the
bend, the graphic is curved one degree in the specified direction. When the Bend handle is active, the current bend (in degrees) is displayed.
Table 5-3: Rotate Actions
Action Nudge Button Touch Screen Keyboard Mouse
Rotate counter-clockwise Left arrow Select and drag the Rotate handle in a
counter-clockwise motion.
Left arrow Click and drag the Rotate handle in a
counter-clockwise motion.
Rotate clockwise Right arrow Select and drag the Rotate handle in a
clockwise motion.
Right arrow Click and drag the Rotate handle in a
clockwise motion.
Note:
When using a keyboard to reposition the graphic, pressing SHIFT+ ARROW KEY will move the active handle 10 degrees in the specified
direction.
Table 5-4: Bend Actions
Action Nudge Button Touch Screen Keyboard Mouse
Bend up Bend up Select and drag the Bend handle downward. Up arrow Click and drag the Bend handle downward.
Bend down Bend down Select and drag the Bend handle upward. Down arrow Click and drag the Bend handle upward.
Note:
When using a keyboard to reposition the graphic, pressing SHIFT+ ARROW KEY will move the active handle 10 degrees in the specified
direction.
