Specifications
General Specifications
The following sections list general specifications for the Cognex VisionView 700 display.
Table 8-1: VisionView 700 Specifications
Specification VisionView 700
Display Size 7" WVGA (16:9 aspect ratio)
Viewable Area 6" (152.4mm) x 3.6" (91.44mm)
Type TFT LCD
Resolution (pixels) 800 x 480 (384,000 pixels)
Number of Colors 262,144 (18 bits/pixel)
Luminance 400 nit
Contrast Ratio
300:1 at minimum 40 ° viewing angle
Backlight Life
10,000 hours to 50% brightness
1
Touch Screen Analog Resistive 4 wire
Life Span >1 Million touches @ 10 - 100 gram-force using a 2mm diameter rubber pointer.
Light Transmission 78% or better
Memory System 64MB Mobile SDRAM
Program 128MB non-volatile flash memory
Video 16MB Video SDRAM
Cooling System Fanless Design
I/O Status LEDs Network or Sensor Traffic (left LED when facing touch screen) and Power (right LED when facing touch screen)
Network 5 Ethernet ports, 10/100 BaseT, TCP/IP protocol, Full Duplex (1 LAN for connecting to wide area network and 4 dedicated sensor ports to
connect Cognex vision sensors directly, additionally supplying power to In-Sight Micro vision systems through Power over Ethernet
2
).
USB
3 Host USB 2.0 (480 Mb/sec.) ports for saving images
3
to a USB drive
4
.
Power Consumption 24VDC ±10%, 2A (1A when not providing Power over Ethernet to In-Sight Micro vision systems). VisionView contains an internal,
self-resetting fuse.
Mechanical Material ABS plastic (V0 UL Rated) housing (polyethylene touch screen and lexan seals/labels)
Mounting Panel. Standalone mounting with optional accessory mounting kit (P/N 820-0005-1R).
Dimensions 170.3mm (6.70in) x 205.9mm (8.10in) x 52.5mm (2.07in)
Weight 860g (30.3 oz.)
