Cognex VisionView - Single Image Mode Controls

28
The sensor’s image includes:
• The job pass, warning or fail status border (if available).
• An AutoSave Failure icon is displayed if the Show
AutoSave Failures checkbox is unchecked and a failed
inspection image is not automatically saved to the specified
location.
Single Image Mode Icons:
Single Image Mode Controls
Sensor Status: Displays information for the active sensor.
• The sensor's Display Name.
• The active job file name.
• Whether the sensor is Online, Offlline, Forced Offline, if an
image is being saved or if the filmstrip is frozen or paused.
• The job pass, warning or fail status (if available).
Offline: Places the sensor Offline. If the sensor is Offline, the
button appears pressed and is displayed in red.
Online: Places the sensor Online. If the sensor is Online, the button
appears pressed and is displayed in green.
Adjust Image: Allows the operator to make adjustments to the
image.
Note:
If the In-Sight sensor is placed Offline using any method
other than the user interface, the sensor status displays
“Forced Offline”. When the sensor is in this state, no job
changes are allowed and the sensor cannot be placed in
Focus Mode. To allow job changes and enable Focus Mode,
place the sensor Offline from the user interface.
AutoSave Failure
Trigger: Triggers an inspection on the sensor.
Switch View: Displays the next view available on the sensor.
Switch View is sensor-specific.
For In-Sight sensors, up to five views are available in the following
default order: 1) image with graphics and EasyView; 2) image with
graphics and Custom View; 3) image only; 4) image with graphics;
and 5) EasyView only.
For DVT sensors, a variable number of views are available in the
following default order: 1) image only; 2) image with graphics; and
3) image with graphics and a SmartLink table.
All Sensors: Transitions the image area from Single Image Mode
to Tiled Image Mode.
Options: Opens the Options screen to configure the available
options for the active sensor.
Filmstrip: The filmstrip displays the sensor’s inspection results. As
results are stored to the sensor, a status icon is added to the
filmstrip. To view a result, touch the status icon in the filmstrip; the
corresponding acquired image and accompanying data (if available
in the current view) are displayed in the image area and the filmstrip
is frozen.
Note:
Custom View and EasyView are optional and configured
within In-Sight Explorer.
Note:
SmartLink tables are optional and configured within Intellect.
The number of views that display a SmartLink table is equal
to the number of SmartLink tables defined on the DVT sensor
for the Product.
