Colortrac M25e - Page 39

M Series Service Manual
Page 39 of 129
7. Remove the screw covers at
both ends and store in a safe
place to prevent damage.
8. Remove the Maintenance
Position Locking Screws and
Springs at both ends of the
Lid Assembly.
9. Release the Motor Control
Cable from the cable clip and
disconnect.
10. Disconnect the Microswitch
Cable.
