14. Rotate the Hold Up Roller
Unit until the threaded hole is
accessible.
15. Rotate the Hold Up Roller
Unit Collar Assembly until it
lines up with the threaded
hole in the Hold Up Roller
Unit.
16. Slide the Hold Up Roller Unit
Collar Assembly across until
the 2 x holes line up.
