InteliLite 9 Global Guide
108
Lamp name Active icon Inactive icon Notes
Malfunction indicator lamp
Note: This value can light
or blink on both
frequencies. This lamp also
activates alarm After-
Treatment (page 368).
Fluid tank low level indicator
Note: This lamp also
activates alarm After-
Treatment (page 368).
DPF regeneration inhibited
Note: Indicates the state of
diesel particulate filter
active regeneration
inhibition. This lamp also
activates alarm After-
Treatment (page 368).
Analog values
Supported analog values:
DPF Ash Load (page 261)
DPF Soot Load (page 261)
DEF Level (page 261)
Control of After-Treatment regeneration function
User can force or inhibit regeneration process by activating appropriate binary inputs of the controller. Please
see the list of binary inputs below:
FORCE REGENERATION (PAGE 305)
REGENERATION INHIBIT (PAGE 310)
5.4.21 Alternate configuration
In controller are 3 sets of configuration.
