InteliLite 9 Global Guide
147
Setpoint group Basic settings Related FW 1.1.0
Range [units] 1 .. 5 000 [A/5A]
Default value 2 000 A/5A Alternative config NO
Step 1 A/5A
Comm object 8274 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Gen-set current transformers ratio.
Note: Generator currents and power measurement is suppressed if current level is below 1% of CT
range.
CT Ratio
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.1.0
Range [units] Load / Gen-set [-]
Default value Gen-set Alternative config NO
Step [-]
Comm object 11625 Related applications AMF
Config level Advanced
Setpoint visibility Always
Description
Adjustment of location of current measurement.
Load: Current CT´s are physically placed on Load (typically between GCB and MCB).
Gen-Set: Current CT´s are physically placed on GenSet (typically before GCB).
Note: For more details about this function see chapter CT Location (page 24).
CT Location
6 back to List of setpoints
Subgroup: Voltage settings
Setpoint group Basic settings Related FW 1.1.0
Range [units] Mono Phase / SplitPhase / 3Ph3Wire / High Leg D / 3Ph4Wire / Autodetect [-]
Default value 3Ph4Wire Alternative config YES
Step [-]
Comm object 11628 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Connection type
