InteliLite 9 Global Guide
89
Events
specification
Protection
type
Description
chapter.
Wrn Maintenance 1 WRN
The period for servicing is set by the Maintenance Timer 1 (page 187)
setpoint. The protection comes if counter reaches zero.
Wrn Maintenance 2 WRN
The period for servicing is set by the Maintenance Timer 2 (page 187)
setpoint. The protection comes if counter reaches zero.
Wrn Maintenance 3 WRN
The period for servicing is set by the Maintenance Timer 3 (page 188)
setpoint. The protection comes if counter reaches zero.
Charge Alternator
Fail
WRN Failure of alternator for charging the battery.
Sd Override WRN The protection is active if the output Sd Override is closed.
Mains CCW Rot WRN
Mains voltage phases are not wired correctly. MCB closing is
prohibited by chontroller.
Generator CCW Rot WRN
Genset voltage phases are not wired correctly. GCB closing is
prohibited by chontroller.
Note: This table does not contain all alarms in controller. It is only list of the most common alarms.
5.4.11 History log
The history log is an area in the controller’s non-volatile memory that records “snapshots” of the system at
moments when important events occur. The history log is important especially for diagnostics of failures and
problems. When the history file is full, the oldest records are removed.
Each record has the same structure and contains:
• The event which caused the record (e.g. “Overspeed alarm” or “GCB closed”)
• The date and time when it was recorded
• All important data values like RPM, kW, voltages, etc. from the moment that the event occurred.
Record structure
Name Abbreviation Description
Number No.
Row number (0 corresponds to the last record, -1 to the previous
one, etc.)
Reason Reason Reason for history record (any event or alarm related to the gen-set
Time Time Time
Date Date Date
RPM RPM Engine rotations per minute
Power Pwr Generator active power
Reactive power Q Generator reactive power
Power Factor PF Generator power factor
Load Character LChr Generator load character
Generator
Gfrq Generator Frequency
