InteliLite 9 Global Guide
124
Web Server Adjustment
Click to the "Web Server settings" icon in the toolbar to display the settings page.
Select the controller language the web pages will appear in.
Select the rate of automatic refresh of the scada page.
Image 6.12 Web Server - Adjustment screen
6 back to Communication
6.2 Connection to 3rd party systems
6.2.1 MODBUS-RTU, MODBUS/TCP 124
6 back to Communication
6.2.1 MODBUS-RTU, MODBUS/TCP
MODBUS protocol is used for integration of the controller into a building management system or for remote
monitoring via 3rd party monitoring tools.
MODBUS-RTU can be used on serial interfaces (CM-RS232-485 module is required). The MODBUS-RTU
server must be activated by switching the setpoint COM1 Mode (page 221) or COM2 Mode (page 223) into
the Modbus position. The serial speed for MODBUS-RTU communication is to be adjusted by the setpoint
COM1 MODBUS Communication Speed (page 222) or COM2 MODBUS Communication Speed (page 224).
