InteliLite 9 Global Guide
248
Setpoint group Basic settings Related FW 1.1.0
Range [units] 45 .. 65 [Hz]
Default value 50 Hz Alternative config YES
Step 1 Hz
Comm object 15197 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Nominal system frequency (usually 50 or 60 Hz).
Note: This value is used when binary input ALTERNATE CONFIG 3 (PAGE 295) is active.
Nominal Frequency 3
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.1.0
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 12054 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type 3 (page 250).
Description
Nominal system voltage (phase to neutral).
Note: This value is used when binary input ALTERNATE CONFIG 3 (PAGE 295) is active.
Nominal Voltage Ph-N 3
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.1.0
Range [units] 80 .. 40 000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 12057 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type 3 (page 250).
Description
Nominal system voltage (phase to phase).
Note: This value is used when binary input ALTERNATE CONFIG 3 (PAGE 295) is active.
Nominal Voltage Ph-Ph 3
6 back to List of setpoints
