55
VECTOR
SELECTING AND CONTROLLING FIXTURES
Figure 17: Parameter wheels, wheel layer keys, and parameter selection keys
Each parameter wheel has 2 associated keys:
ATTENTION! In Vector Violet you can select a parameter by clicking
on the wheel itself.
Double clicking on the wheel opens the picker for the parameters if the
picker exists (for example color wheel picker).
BEAM
Focus, zoom, iris
Gobo wheels, prism, gobo spin.
SHAPE
Framing shutters, frost
Parameter
wheel key
What it does
Left key Pages the bank layers when the parameter bank includes
more than 5 parameters.
Right key Selects the parameter.
Parameter wheel and the associated keys
Wheel banks
(Parameter
types)
Possible parameters
