Mentor ll User Guide 31
Issue Number: 12 www.controltechniques.com
Menu 05 Current Loop
Number Description Range Type Default
05.01 Current feedback ±1000 RO
05.02 Current feedback (amps) ±1999 RO
05.03 Firing angle 277 ~ 1023 RO
05.04 Slew rate limit 0 ~ 255 RW 040
05.05 Maximum current (scaling) 0 ~ 1999 RW (rating)
05.06 Overload threshold 0 ~ 1000 RW + 700
05.07 Overload integrating time (heating) 0 ~ 255 RW 030
05.08 Overload integrating time (cooling) 0 ~ 255 RW 050
05.09 Enable start-up autotune 0 or 1 RW 0
05.10 Reduced endstop 0 or 1 RW 0
05.11 Actual overload 0 ~ 1999 RO
05.12 Discontinuous Integral gain 0 ~ 255 RW 16
05.13 Continuous Proportional gain 0 ~ 255 RW 16
05.14 Continuous Integral gain 0 ~ 255 RW 16
05.15 Motor constant 0 ~ 255 RW 25
05.16 Reserved
RW
05.17 Inhibit firing 0 or 1 RW 0
05.18 Enable standstill logic 0 or 1 RW 1
05.19 Standstill mode 0 or 1 RW 0
05.20 Enable direct firing angle control 0 or 1 RW 0
05.21 Enable bridge 2 lockout 0 or 1 RW 0
05.22 Disable adaptive control 0 or 1 RW 0
05.23 Enable 1 quadrant series 12-pulse 0 or 1 RW 0
05.24 Series 12-pulse operation 0 or 1 RW 0
05.25 Parallel 12-pulse operation 0 or 1 RW 0
05.26 Extra-safe bridge change 0 or 1 RW 0
05.27 Continuous autotune 0 or 1 RW 0
05.28 Reduced hysteresis for bridge changeover 0 or 1 RW 0
05.29 Increased current feedback 0 or 1 RW 0
