32 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
Menu 06 Field Control
* Dependent on MDA3 card issue (revision) number
** FXM5 Field Controller only
Number Description Range Type Default
06.01 Back emf 0 ~ 1000 RO
06.02 Field current demand 0 ~ 1000 RO
06.03 Field current feedback 0 ~ 1000 RO
06.04 Firing angle 261 ~ 1000 RO
06.05 IR compensation 2 output ±1000 RO
06.06 IR compensation 2 0 ~ 255 RW 000
06.07 Back emf set point 0 ~ 1000 RW + 1000
06.08 Maximum field current 1 0 ~ 1000 RW + 1000
06.09 Maximum field current 2 0 ~ 1000 RW + 500
06.10 Minimum field current 0 ~ 1000 RW + 500
06.11 Field current feedback scaling* 201 ~ 216 RW +204
06.12 Field economy timeout 0 ~ 255 RW 030
06.13 Enable field control 0 or 1 RW 0
06.14 Maximum field 2 selector 0 or 1 RW 0
06.15 Enable field economy timeout 0 or 1 RW 0
06.16 Field current loop integral gain 0 or 1 RW 1
06.17 Voltage loop integral gain 0 or 1 RW 0
06.18 Enable speed gain adjustment 0 or 1 RW 0
06.19 Direct firing angle control 0 or 1 RW 0
06.20 Alternative IR Comp. 2 selector 0 or 1 RW 0
06.21 Firing angle front endstop 0 ~ 1000 RW +1000
06.22 Full or half control selector** 0 or 1 RW 0
06.23 Reduce gains by factor of 2 0 or 1 RW 0
06.24 Reduce gains by factor of 4 0 or 1 RW 0
