Menu 07 Analog Inputs and Outputs
Number Description Range Type Default
07.01 General purpose input 1 ±1000 RO
07.02 General purpose input 2 ±1000 RO
07.03 General purpose input 3 ±1000 RO
07.04 General purpose input 4 ±1000 RO
07.05 Speed reference input ±1000 RO
07.06 RMS input voltage 0 ~ 1000 RO
07.07 Heatsink temperature 0 ~ 1000 RO
07.08 DAC 1 source 0 ~ 1999 RW + 201
07.09 DAC 2 source 0 ~ 1999 RW + 302
07.10 DAC 3 source 0 ~ 1999 RW + 304
07.11 GP1 destination 0 ~ 1999 RW + 318
07.12 GP2 destination 0 ~ 1999 RW + 408
07.13 GP3 destination 0 ~ 1999 RW + 119
07.14 GP4 destination 0 ~ 1999 RW + 120
07.15 Speed reference destination 0 ~ 1999 RW + 117
07.16 GP1 scaling 0 ~ 1999 RW +1000
07.17 GP2 scaling 0 ~ 1999 RW +1000
07.18 GP3 scaling 0 ~ 1999 RW +1000
07.19 GP4 scaling 0 ~ 1999 RW +1000
07.20 Speed reference scaling 0 ~ 1999 RW +1000
07.21 DAC1 scaling 0 ~ 1999 RW +1000
07.22 DAC2 scaling 0 ~ 1999 RW +1000
07.23 DAC3 scaling 0 ~ 1999 RW +1000
07.24 Reference encoder scaling 0 ~ 1999 RW +419
07.25 Encoder reference selector 0 or 1 RW 0
07.26 Current input selector 0 or 1 RW 0
07.27 Current sense inverter 0 or 1 RW 0
07.28 4mA offset selector 0 or 1 RW 1
07.29 Invert GP3 and GP4 analog inputs 0 or 1 RW 0
