Installation
July 22, 2019 | 287960-ENG | R00 11
3. Lift the chamber straight up and remove the pallet from underneath the chamber.
4. Lower the chamber to the floor.
To remove the chamber from the pallet using the optional ramp:
1. Remove the packing material and lower the ramp (Figure 3-3, Panels 1 & 2).
2. Remove the wooden brace and metal shipping bracket (Figure 3-3, Panel 3 & 4) from
both sides of the pallet.
3. Ensure the locks on the front casters are in the unlocked position (Figure 3-3,
Panel 5).
4. Slowly roll the chamber down the ramp (Figure 3-3, Panel 6).
Figure 3-3 Remove the Chamber from the Pallet Using the Optional Ramp
Warning: Severe equipment damage and potential personal injury hazard
Only a trained forklift operator should attempt to remove the chamber from the pallet.
Ensure the chamber is secured to the forklift before attempting to lift it off of the
Warning: Personal injury hazard
Do not leave any nails, staples, or screws protruding from the crating material to
eliminate potential puncture injuries.
Recycle or properly dispose of the crating material and shipping pallet.
Warning: Personal injury hazard
Do not lose control of the chamber speed while removing it from the pallet.
At least two people are required to control the speed of the chamber while rolling it off
the shipping pallet and down the ramp.
