Operation
July 22, 2019 | 287960-ENG | R00 39
5.4 Aspirator
Located in the growth area, the aspirator houses the sensors used to monitor temperature and
humidity levels within the chamber. The aspirator receives an air sample from the room to
measure and control conditions and provides shielding from the chamber lighting to prevent
false readings caused by radiant energy.
Figure 5-1 Aspirator
5.5 Instrumentation Port
The instrumentation port with a threaded closure is located on the lower-right side of the
chamber (Figure 5-2). The port enables instrument probes, and small hoses, etc. to be passed
through the wall of the cabinet for connection to equipment within the cabinet growth
environment.
Failure to burn in the fluorescent lamps before dimming will significantly reduce the life
of the tubes.
The instrumentation port is intended for low-voltage wires only. Conviron does not
recommend the use of extension cords inside the chamber.
