Conviron GEN1000 - DIAGNOSTIC INFORMATION; Fuse Schedule

GEN1000 Operator Manual
54 July 22, 2019 | 287960-ENG | R00
7.2 Fuse Schedule
Fuse
Description
Conviron
P/N
Location
System/Component
Protected
F1
FUSE - 2.5A, 250V, MDL, TIME DELAY
233327
Main Control Panel
PLC Controller
F2
FUSE - 0.75A, 250V, ABC, FAST ACTING
79815
Main Control Panel
Central Alarm
F3
FUSE - 2.5A, 250V, MDL, TIME DELAY
233327
Main Control Panel
USH Unit
F4
FUSE - 1A, 250V, ABC, FAST ACTING
742296
Main Control Panel
Condensate Pump
F5
FUSE - 2.5A, 250V, MDL, TIME DELAY
233327
Transformer Mtg
Plate (50Hz UPS
option only)
UPS Transformer
F6
FUSE - 4A, 250V, MDL, TIME DELAY
291767
Transformer Mtg
Plate (50Hz
chamber only)
Lighting Transformer
