Installation
July 22, 2019 | 287960-ENG | R00 15
3.5.3 Unifloor® (TA Kit)
The Unifloor
®
, available only in the TA Kit, has openings that allow conditioned air to be
distributed evenly up through the floor into the chamber. Excess irrigation water and condensate
will drain out of the chamber to the floor drain.
Figure 3-8 Unifloor
3.6 Install the Light Canopies and Shelving Configuration Kits
Conviron chambers are configured onsite using one of four pre-packaged lighting and shelving
kits; SH for short plants, TA, for tall plants, TC for tissue culture, or IN for incubator
configuration.
To ensure proper airflow and water drainage, keep the vents and drain channels in
the Unifloor clear of debris.
Images used in the installation instruction may differ from the actual kit. However, the
installation steps and procedures are the same.
