GEN1000 Operator Manual
16 July 22, 2019 | 287960-ENG | R00
3.6.1 SH Configuration
Horizontal airflow (Figure 3-5) across shelves optimizes growth area for shorter plants by forcing
the air through the perforated interior rear wall of the chamber. Cover plates are installed over
the opening in the rear wall to provide an even airflow.
The SH configuration may include an optional extra shelf and light canopy .The optional LED
lighting canopies are installed the same way as fluorescent light canopies.
Figure 3-9 SH Configuration
Figure 3-10 SH X-TIER Configuration
