Conviron GEN1000 - Connect the Electrical Cord; Table 3-2 Back Panel Connection Descriptions

GEN1000 Operator Manual
34 July 22, 2019 | 287960-ENG | R00
Table 3-2 Back Panel Connection Descriptions
Item
Description
Usage
1
Power Cord
Plug the power cord into a receptacle on a
dedicated circuit after all other connections have
been made.
2
A/C Power to UPS
The UPS has two connection cables. One is power
to the UPS and the other is power from the UPS to
the control system. The plug and receptacle are
keyed and dedicated to the UPS and are not be
used for any other purpose.
3
Backup A/C Power From UPS
4
Central Alarm Contact (CAC)
The receptacle is dedicated for the CAC connection.
The receptacle is mated with the plug and then
screwed tightly together.
5
Optional Condensate Pump Connection
This receptacle is dedicated for the drain pan pump
which is a purchasable option. The plug is mated
with the receptacle and then screwed tightly
together.
6
RJ-45 Communications Port
Connect an RJ-45 terminated cable to the facility
network.
3.9 Connect the Electrical Cord
All power and grounding connections must be made in accordance with this manual and local
regulations.
Plug the power cord into a receptacle on a dedicated circuit after all other connections have
been made.
The Central Alarm Contact is rated for 230VAC at 0.5 amperes.
A power cord plug end is not supplied with the product on 50 Hz models. The cord
end supplied by the client must be wired in accordance with applicable electrical
codes. Hot, neutral, and ground connections must be verified by a locally qualified
person.
Observe the following precautions when handling the 60 Hz power cord:
 Handle the power cord carefully and protect it from damage.
 Hold the plug when unplugging the power cord. Do not pull on the cord.
 Do not handle the power cord with wet hands.
 Do not bend or modify the ground pin.
